SFERAX STANDARD SWISS1017 high precison linear bearing

SFERAX STANDARD SWISS1017  linear bearing

Enterprise purposes: quality first customer first!

Benes Bearing have successfully provided quality services for 107 countries and regions.We have an excellent design and development department.

On the basis of these strategies, the mode of product development and manufacturing for mass customization is researched. We can customize products according to the customers' requirement.

24 hours online : service@benesbearing.com
SFERAX STANDARD SWISS1017  linear bearing

Application
This ball bearing has high manufacturing standards, as well as all the fundamental qualities to ensure very high precision linear movements, without any stroke limitation, without play and
practically free of friction and wear.

Advantages
– Brass precision-milled ball tray (GBL)
– Smooth, jerk-free operation
– Noiseless

Datasheet

Product Number 1010.001017.10
Product Designation SFERAX STANDARD GBL 1017 B
Net Weight 18 g
Outer diameter D 17
Inner diameter d 10
Length 22 mm
Tolerance Inner diameter 0/+20 µm
Tolerance outer diameter 0/-12 µm
Tolerance length 0/-350 µm
Max. eccentricity <15 µm
Recommended tolerance on the shaft h6
Dynamic load capacity 445.5
Static load capacity N 495
Dynamic factor Y 0.00202
Diameter balls b 2.000 mm
Diameter bottom of grooves D1 16.3 mm
Spacing grooves (0/+01 mm) E 16 mm
Width groove 0/+0.1 mm e 1.00 mm
Cage material DIN MS60Pb (17660)
Housing material DIN 100Cr6 (1.3505)
Number of ball tracks 6
Operating temperature -30 / +80°C
Precision class B
Recommended shaft quality III
Tolerance Bore (pressed mounted) -2/-10 µm
Tolerance bore (glue mounted) H6
