Angular Contact Ball Bearings 7224bgam 7224bm 7324bcbm

Angular contact ball bearings
High Quality Steel - Ultra clean steel to extend bearing life by up to 80%.
Advanced Grease Technology - NSK lubricants that can extend grease life and performance.
High Grade Balls - Quiet and smooth operation even at high speed.
Super Finished Raceways - Specially honed to minimise noise and improve lubricant distribution and life.
Contact Angle - Offered in 15, 25, 30 and 40 degree angles.
Cages - Available in a range of Polyamide, steel and brass cage assemblies.


Principaldimensions			Designation
d[mm]	D[mm]	B[mm]
60	110	22	7212BEP
60	110	22	7212BECBJ
60	110	22	7212BECBP
60	110	22	7212BECBPH
60	110	22	7212BECBY
60	110	22	7212BEGAP
60	110	22	7212BEGBP
60	110	22	7212BECBM
60	110	22	7212BEGAM
60	110	22	7212ACCBM
60	130	31	7312BEP
60	130	31	7312BECAP
60	130	31	7312BECBJ
60	130	31	7312BECBP
60	130	31	7312BECBPH
60	130	31	7312BECBY
60	130	31	7312BEGAP
60	130	31	7312BEGAY
60	130	31	7312BEGBP
60	130	31	7312BEGBY
60	130	31	7312BECBM
60	130	31	7312BECCM
60	130	31	7312BEGAM
60	130	31	7312BEGBM
60	130	31	7312ACCBM
60	150	35	7412BCBM
60	150	35	7412BGAM
60	150	35	7412BGBM
60	150	35	7412BM
65	120	23	7213BEGAF
65	120	23	7213BEP
65	120	23	7213BECBJ
65	120	23	7213BECBP
65	120	23	7213BECBY
65	120	23	7213BEGAP
65	120	23	7213BEGAPH
65	120	23	7213BECBM
65	120	23	7213ACCBM
65	140	33	7313BECBF
65	140	33	7313BEGAF
65	140	33	7313BEP
65	140	33	7313BECBJ
65	140	33	7313BECBP
65	140	33	7313BECBPH
65	140	33	7313BECBY
65	140	33	7313BEGAP
65	140	33	7313BEGBP
65	140	33	7313BEGBY
65	140	33	7313BECBM
65	140	33	7313BECCM
65	140	33	7313BEGAM
65	140	33	7313BEGBM
65	140	33	7313ACCBM
65	160	37	7413BGBM
65	160	37	7413BCBM
69.85	158.75	34.925	AMS22ABP
70	125	24	7214BEGAF
70	125	24	7214BEP
70	125	24	7214BECBJ
70	125	24	7214BECBP
70	125	24	7214BECBPH
70	125	24	7214BECBY
70	125	24	7214BEGAP
70	125	24	7214BECBM
70	125	24	7214BEGAM
70	125	24	7214ACCBM
70	150	35	7314BEGAF
70	150	35	7314BEP
70	150	35	7314BECAP
70	150	35	7314BECBJ
70	150	35	7314BECBP
70	150	35	7314BECBPH
70	150	35	7314BECBY
70	150	35	7314BEGAJ
70	150	35	7314BEGAP
70	150	35	7314BEGAPH
70	150	35	7314BEGAY
70	150	35	7314BEGBY
70	150	35	7314BECBM
70	150	35	7314BEGAM
70	150	35	7314ACCBM
70	180	42	7414BCBM
70	180	42	7414BGAM
75	130	25	7215BEP
75	130	25	7215BECBJ
75	130	25	7215BECBP
75	130	25	7215BECBPH
75	130	25	7215BEGAP
75	130	25	7215BECBM
75	130	25	7215BECBY
75	130	25	7215BEGAM
75	130	25	7215BEGAY
75	160	37	7315BEP
75	160	37	7315BECBJ
75	160	37	7315BECBP
75	160	37	7315BECBY
75	160	37	7315BEGAP
75	160	37	7315BEGAPH
75	160	37	7315BECBM
75	160	37	7315BEGAM
75	190	45	7415BCBM
75	190	45	7415BGAM
75	190	45	7415BGBM
76.2	177.8	39.688	AMS24ABP
80	140	26	7216BEGAF
80	140	26	7216BEGAP
80	140	26	7216BEP
80	140	26	7216BECBJ
80	140	26	7216BECBP
80	140	26	7216BECBPH
80	140	26	7216BECBY
80	140	26	7216BEGAPH
80	140	26	7216BECBM
80	140	26	7216BEGAM
80	170	39	7316BEP
80	170	39	7316BECBJ
80	170	39	7316BECBP
80	170	39	7316BECBPH
80	170	39	7316BECBY
80	170	39	7316BEGAP
80	170	39	7316BEGAY
80	170	39	7316BEGBY
80	170	39	7316BECBM
80	170	39	7316BECCM
80	170	39	7316BEGAM
80	200	48	7416GAM
80	200	48	7416M
80	200	48	7416CBM
85	150	28	7217BEGAF
85	150	28	7217BEGAP
85	150	28	7217BEP
85	150	28	7217BECBJ
85	150	28	7217BECBP
85	150	28	7217BECBY
85	150	28	7217BECBM
85	180	41	7317BECBF
85	180	41	7317BEGAF
85	180	41	7317BEP
85	180	41	7317BECBJ
85	180	41	7317BECBP
85	180	41	7317BECBY
85	180	41	7317BEGAP
85	180	41	7317BEGAPH
85	180	41	7317BECBM
85	180	41	7317BECCM
85	180	41	7317BEGAM
85	210	52	7417BACBMC
85	210	52	7417BAGAMC
88.9	165.1	28.575	ALS28ABP
90	160	30	7218BEGAF
90	160	30	7218BEP
90	160	30	7218BEGAM
90	160	30	7218BECBJ
90	160	30	7218BECBP
90	160	30	7218BECBY
90	160	30	7218BECCM
90	160	30	7218BEGAP
90	160	30	7218BEGAY
90	160	30	7218BECBM
90	190	43	7318BEP
90	190	43	7318BECBJ
90	190	43	7318BECBP
90	190	43	7318BECBY
90	190	43	7318BEGAP
90	190	43	7318BEGAPH
90	190	43	7318BEGAY
90	190	43	7318BECBM
90	190	43	7318BEGAM
90	225	54	7418GAM
90	225	54	7418CBM
95	170	32	7219BEP
95	170	32	7219BECBP
95	170	32	7219BECBY
95	170	32	7219BEGAPH
95	170	32	7219BECBM
95	170	32	7219BEGAM
95	200	45	7319BEGAF
95	200	45	7319BEP
95	200	45	7319BEM
95	200	45	7319BECBP
95	200	45	7319BECBY
95	200	45	7319BEGAP
95	200	45	7319BEGAY
95	200	45	7319BEGBY
95	200	45	7319BECBM
95	200	45	7319BEGAM
95	250	55	7419CBM
95	250	55	7419GAM
95	250	55	7419M
100	180	34	7220BEP
100	180	34	7220BECBM
100	180	34	7220BECCM
100	180	34	7220BEGAM
100	180	34	7220BECBP
100	180	34	7220BECBY
100	180	34	7220BEGAY
100	215	47	7320BEGAF
100	215	47	7320BEM
100	215	47	7320BEP
100	215	47	7320BECBP
100	215	47	7320BECBY
100	215	47	7320BEGAP
100	215	47	7320BEGBY
100	215	47	7320BECBM
100	215	47	7320BECCM
100	215	47	7320BEGAM
100	265	60	7420CBM
101.6	184.15	31.75	ALS32ABP
105	190	36	7221BEP
105	190	36	7221BECBP
105	190	36	7221BECBM
105	225	49	7321BEP
105	225	49	7321BECBP
105	225	49	7321BECBM
105	225	49	7321BEGAM
110	200	38	7222BEGAF
110	200	38	7222BEP
110	200	38	7222BECBP
110	200	38	7222BECBY
110	200	38	7222BECBM
110	200	38	7222BECCM
110	240	50	7322BEP
110	240	50	7322BEM
110	240	50	7322BECBP
110	240	50	7322BECBY
110	240	50	7322BECBM
110	240	50	7322BECCM
110	240	50	7322BEGAM
110	240	50	7322BEGBM
120	180	28	7024BGM
120	215	40	7224BCBM
120	215	40	7224BGAM
120	215	40	7224BM
120	260	55	7324BCBM
120	260	55	7324BGAM
120	260	55	7324BGBM
127	228.6	34.925	ALS40ABM
130	230	40	7226BGAF
130	230	40	7226BCBM
130	230	40	7226BGAM
130	230	40	7226BM
130	280	58	7326BCBM
130	280	58	7326BGAM
130	280	58	7326BM
140	210	33	7028BGM
140	250	42	7228BCBM
140	250	42	7228BGAM
140	250	42	7228BM
140	300	62	7328BCBM
140	300	62	7328BGAM
150	225	35	7030BGM
150	270	45	7230BCBM
150	270	45	7230BGAM
150	320	65	7330BCBM
150	320	65	7330BGAM
160	290	48	7232BCBM
160	290	48	7232BGAM
160	340	68	7332BCBM
170	260	42	7034BGM
170	310	52	7234BCBM
170	360	72	7334BCBM
180	280	46	7036BGM
180	320	52	7236BCAM
180	320	52	7236BCBM
180	380	75	7336BCBM
190	290	46	7038BGM
190	340	55	7238BCBM
190	400	78	7338BCBM
200	310	51	7040BGM
200	360	58	7240BCBM
200	420	80	7340BCBM
220	340	56	7044BGM
220	400	65	7244BCBM
220	460	88	7344BCBM
240	360	56	7048BGM
240	440	72	7248BCBM
240	500	95	7348BCBM
260	400	65	7052BGM
260	480	80	7252BM
280	420	65	7056BGM
280	500	80	7256BM
300	460	74	7060BGM
300	460	74	7060AGM
300	540	85	7260BCBM
320	440	56	71964AC
320	480	74	7064BGM
320	580	92	7264BCBM
340	460	56	71968ACMB
340	520	82	7068BGM
360	440	38	71872ACMB
360	480	56	71972BM
360	480	56	71972AMB
360	480	56	71972ACMB
360	540	82	7072BGM
360	540	82	7072AGM
360	540	82	7072AM
380	480	31	70876AMB
380	480	46	71876ACGAMB
380	520	65	466953
380	520	65	71976ACGAMB
380	560	82	7076BGM
380	560	82	7076BM
380	560	82	7076AM
400	540	65	71980AM
400	600	90	7080BM
400	600	90	307238
400	600	90	7080AM
400	720	103	7280BM
410	560	70	468431
420	560	65	71984BM
420	560	65	71984AGAM
420	560	65	71984AM
420	620	90	7084BGM
420	620	90	7084AM
440	600	74	71988ACMB
440	650	94	7088BM
440	650	94	7088AM
460	580	37	70892AM
460	580	56	71892AGMB
460	620	74	71992ACM
460	680	100	7092BM
460	680	100	7092AM
480	700	100	7096BM
480	700	100	7096AM
500	620	37	708/500AMB
500	620	56	718/500AGMB
500	620	56	718/500AMB
500	670	78	719/500AGMB
500	720	100	70/500BM
500	720	100	70/500AM
530	650	56	718/530AMB
530	710	82	719/530ACM
530	780	112	70/530BM
530	780	112	70/530AM
540	630	45	BA1B311585A
560	680	56	718/560AMB
560	750	85	719/560AMB
560	820	115	70/560AMB
600	730	42	708/600AGMB
600	730	42	708/600AMB
600	730	60	718/600AMB
600	800	90	719/600ACM
600	870	118	70/600AGMB
630	920	128	70/630AMB
670	820	69	718/670AMB
670	820	69	718/670ACMB
670	980	136	70/670AMB
710	870	74	718/710AMB
710	870	74	718/710ACMB
710	950	106	719/710ACMB
710	1030	140	70/710AMB
750	920	78	718/750AGMB
750	920	78	718/750ACMB
750	1090	150	70/750AMB
762	889	63.5	BA1B311576
800	1150	155	70/800AMB
850	1030	82	718/850AMB
850	1220	165	70/850AMB
900	1030	63	BA1B307788
900	1280	170	70/900AMB
950	1360	180	70/950AMB
1000	1220	100	718/1000AMB
1000	1420	185	70/1000AMB
1060	1500	195	70/1060AMB
1120	1360	106	718/1120AMB
1120	1580	200	70/1120AMB
1180	1660	212	70/1180AMB
1250	1500	80	708/1250AMB
1250	1500	112	718/1250AMB
1250	1750	218	70/1250AMB
